Feature Description & Operation Manual Issue 6.0d1
310
LOOP Example for self testing)
Signal/Voice port 1 <-> Signal/Voice port 3
Signal/Voice port 2 <-> Signal/Voice port 4
Program
ADM 149-3B : 2W Set
4W Method
Setting of External Analogue port
1. Connect first signal port to alternate second odd line.
2. Voice port must connect first voice port to alternate fourth line and own second
port to third line.
3. Signal port must be crossed line.
4. Second and Forth line should be programmed unused ports.
*) 4W method is like the way of use only 2 ports even there are 4 ports.
LOOP Example for self testing)
Sinal port 1 <-> Sinal port 3
Voice port 1 <-> Voice port 4
Voice port 2 <-> Voice port 3
Program
5. ADM 149-3B : 4W
6. ADM 141-1B : 2,4 ports should be set unused groups
Conditions
Programming
CO
2 PROGRAM 149-B 3 (2w/4w)
3 PROGRAM 149-B 1( EMC(4) )
Related Features
Hardware
4.18.2 LD/RD/LCO Trunk Function
기능 설명
LD, RD and LCO are the module for analogue line and LCO is the same of LGCM module.
