iPECS-LIK
Feature Description & Operation Manual Issue 6.0d1
169
Flex Field II for incoming call, displays Ring duration, CLI or CPN or
blank, (PGM 177-Btn 23)
Disconnect Cause, optional output (PGM 177-Btn 29), with value:
01~7F: Follow cause value of Q.931 specification,
81: Disconnected, toll restricted
84/85: Disconnected, disconnect supervision
0: Other
The SMDR record output for internal calls is as shown in the figure below.
---- Site Name : -----------------------------------------------------------------------------------------
1) Station 100 called station 101 and station 101 answered.
2) In a conference, station 100 was a conference master, station 101 was a
conference member.
Station 105 sent an internal SMS to station 103.
Station 110 was the member of conference room 1.
Station 120 paged station 123.
Operation
System
For real-time SMDR, records are output after completion of the call as shown in the figure
above
System Attendant
To print SMDR records
1. Press the [PGM] button.
2. Dial “0111”, the SMDR print code.
3. Enter the desired station range.
4. Press the [SAVE] button.
To delete stored records
1. Press the [PGM] button.
2. Dial “0112”, the SMDR delete code.
3. Enter the desired station range.
4. Press the [SAVE] button.
