Chapter 1 BASIC INFORMATION
1-4 UNI-5 Service Manual
1.2 SPECIFICATIONS
Items Descriptions
Use conditions Temperature: -5 to 35°C
Humidity: 30 to 85%, Non condensing.
Power supply: AC100 – 240V, 50 / 60Hz
Power consumption 1.0A/0.5A
Weighing capacity
Scale interval
15 kg: 0 to 6/0.002 kg, 6 to 15/0.005 kg
30 lb: 0 to 15/0.005 lb, 15 to 30/0.01 lb
Weighting accuracy 1/3000
Operator/Customer display 7.0 inch color liquid crystal with back light, 480 X 234dots
Printing method Direct thermal method
Thermal head 2 inches (448dots) and 8 dots/mm
Printing speed 100mm/second, 120mm/second
Note: The printing speed may vary according to label conditions.
Printing effective size 56mm
Label size Label width: 30mm to 60mm
Label length: 20mm to 150mm
Input/Output LAN 1 channel
USB 1 channel
CF 1 channel
Drawer 2 channels
Program store medium Flash ROM (32M bytes)
