Chapter 6 MECHANICAL ADJUSTMENT
6-4 UNI-5 Service Manual
6.4 THERMAL HEAD POSITION
1.
Open the side cover.
2.
Raised the lock bar.
3.
Squeeze the springs by holding up the
head bracket and pull out the thermal head
unit.
4.
Loosen the two screws to adjust the gap
between the bracket and the left end of the
thermal head.
5.
Thermal head
To Next Page
