Chapter 5 MACHINE DISASSEMBLY
UNI-5 Service Manual 5-3
5.1.3 MAIN BOARD
1.
Unplug all harnesses connected to the main
board.
2.
Remove the three screws fixing the main
board.
3.
Squeeze the two spacers to remove the
main board.
Reverse this procedure for assembly.
