ISHIDA Uni-5 Service Manual

Chapter 6 MECHANICAL ADJUSTMENT
UNI-5 Service Manual 6-3
6.3 PRINT POSITION
1.
Open the side cover.
2.
This photo shows the position of the
thermal head unit.
3.
Loosen the two screws and move the thermal head unit back and forth and around for position
adjustment. Be sure to tighten the screws after adjustment.
Thermal head unit
