Chapter 5
MACHINE DISASSEMBL
Y
5-22
UNI-5 Service Manual
5.4.3
ELEV
A
TED
UNIT
1.
T
urn to remove the level
adjusting foot.
2.
Remove the three screws fixing the pole
bottom cover
.
3.
Remove the three hexagon socket head
bolts fixing the elevated unit.
