ISHIDA Uni-5 Service Manual

Chapter 5 MACHINE DISASSEMBLY
5-18 UNI-5 Service Manual
5.3.2 PANEL CONTROL BOARD
1.
Lift to disengage the two hooked places and detach the blind cover of the self-service panel unit..
2.
Remove the four screws to detach the rear
cover.
Panel control board
Rear cover
Blind cover
