Chapter 2 ASSEMBLY DRAWINGS
2-2 UNI-5 Service Manual
Parts List (Bench Type)
NO. PART NAME Q'TY NO. PART NAME Q'TY
1 GUIDE PLATE 1 45 BRACKET CONNECTOR ASSY 1
2 PLATTER ASSY 1 46 PWB PK-265A 1
3 CASE MAIN UPPER 1 47 HARNESS C4 SWITCH ASSY 1
4 COVER PRINTER UPPER 1 48 COVER SWITCH 1
5 COVER HINGE UPPER 1 49 STICKER 'SEAL' 2
6 COVER HINGE LOWER 1 50 ANTENNA 1
7 PLATTER SUPPORT 1 51 COVER BRACKET CONNECTOR 1
8 BLOCK B HINGE PLATTER 2 52 BASE 1
9 RUBBER PLATER SUPPOR 5 53 STICKER VOID 2
13 CASE A/D BOARD 1 54 PLATE B RS232C 1
14 PWB P-999B 1 56 BLOCK B HINGE SIDE COVER 1
15 SCREW 'SEAL' HEXA 1 57 FOOT ADJUST 4
16 SCREW 'SEAL' HEXA 1 58 COVER SIDE 1
17 PWB PK-270C 1 59 COVER HARNESS 1
18 HARNESS S2 5V POWER 1 60 POWER SUPPLY 1
19 HARNESS S2 REAR LCD 1 61 BRACKET POWER 1
20 HARNESS S2 FRONT LCD 1 62 CASE REAR COVER 1
21 FERRITE CORE 3 63 PWB PK-263A 1
22 FERRITE CORE 2 64 LCD 1
23 SHEET INSULATION 1 65 CASE REAR PANEL 1
24 ACCESSORY PWB GUIDE SPACE 2 66 CAP 4
25 HARNESS S2 24V DC POWER 1 67 HARNESS C2 POWER ASSY 1
26 SHEET DOUBLE TAPE 1 68 SHEET KEY BOARD-PLU 1
27 HARNESS C2 A/D 1 70 HARNESS S2 LAN 1
28 BRACKET LEVEL 1 71 STICKER LOCATION OUTPUT 1
29 LEVEL UNIT 1 72 GASKET 20mm 1
30 FRAME LEVEL 1 73 STICKER IMPORTANT 1
31 LEVEL LENS 1 74 GASKET 115mm 1
32 BRACKET HINGE 1 75 FERRITE CORE 1
33 HINGE L 1 76 LOADCELL ASSEMBLY 1
34 HINGE R 1 77 SHEET INSULATION POWER SUPPLY 1
35 EARTH CLAMP 4 78 POWER CORD 1
36 CASE REAR CONTROLL 1 79 STICKER 'M' 1
37 PWB PK-261A 1 83 HARNESS C2 HEAD 1
38 ACCESSORY PCB SUPPORT 4 84 HARNESS C3 SENSOR 1
39 BRACKET LCD 2 85 COVER PRINTER 1
40 LCD TOUCH 1 86 MAGNETIC 1
41 CASE FRONT CONTROLL 1 87 STICKER LABEL SETTING 1
42 KEY BOARD MEMBRANE 1 88 BRACKET LABEL PEEL 1
43 SHEET KEY BOARD-SETTING 1 89 PLATE A COVER 1
44 COVER KEY BOARD 1 90 FRONT LCD ASSY 1
