Chapter 2 ASSEMBLY DRAWINGS
2-4 UNI-5 Service Manual
Parts List (Pole Type)
NO. PART NAME Q'TY NO. PART NAME Q'TY
1 GUIDE PLATTER 1 49 STICKER SEAL 3
2 PLATTER ASSY 1 50 ANTENNA 1
3 CASE MAIN UPPER 1 51 COVER BRACKET CONNECTOR 1
4 COVER PRINTER UPPER 1 52 BASE 1
5 COVER HINGE UPPER 1 53 STICKER VOID 2
6 COVER HINGE LOWER 1 54 PLATE B RS232C 1
7 PLATTER SUPPORT 1 56 BLOCK B HINGE SIDE COVER 1
8 BLOCK B HINGE PLATTER 2 57 FOOT ADJUST 4
9 RUBBER PLATTER SUPPORT 5 58 COVER SIDE 1
13 CASE A/D BOARD 1 59 COVER HARNESS 1
14 PWB P-999B 1 60 POWER SUPPLY 1
15 SHEET KEY BOARD-PLU 1 61 BRACKET POWER 1
16 SCREW SEAL HEXA 1 62 CASE REAR POLE 1
17 PWB PK-270C 1 63 PLATE B BRACKET POLE 1
18 HARNESS S2 5V POWER 1 64 BRACKET POLE STAND 1
19 HARNESS S2 REAR LCD
POLE
1 65 POLE STAND 1
20 HARNESS S2 FRONT LCD 1 66 CASE LINK POLE 1
21 GASKET 115mm 1 67 CAP 6
22 FERRITE CORE 2 68 CASE REAR POLE DISPLAY 1
23 FERRITE CORE 2 69 PWB PK-263A 1
24 ACCESSORY PWB GUIDE SPACER 4 70 LCD 1
25 HARNESS S2 24V DC POWER 1 71 CASE FRONT POLE DISPLAY 1
26 SHEET INSULATION 1 72 SHEET DISPLAY PANEL 1
27 HARNESS C2 A/D 1 73 SCREW SEAL HEXA 1
28 BRACKET LEVEL 1 74 HARNESS C2 POWER ASSY 1
29 LEVEL UNIT 1 75 STICKER 'M' 1
30 FRAME LEVEL 1 77 STICKER LOCATION OUTPUT 1
31 LEVEL LENS 1 78 GASKET 20mm 1
32 BRACKET HINGE 1 79 SHEET DOUBLE TAPE 1
33 HINGE L 1 80 COVER CASSETTE 1
34 HINGE R 1 81 FERRITE CORE 1
35 EARTH CLAMP 4 82 LOADCELL ASSEMBLY 1
36 CASE REAR CONTROLL 1 83 SHEET INSULATION POWER SUPPLY 1
37 PWB PK-261A 1 84 POWER CORD 1
38 ACCESSORY PCB SUPPORT 4 85 NAME PLATE SPEC 2
39 BRACKET LCD 2 86 NAME PLATE SERIAL 1
40 LCD TOUCH 1 87 FERRITE CORE 1
41 CASE FRONT CONTROLL 1 88 HARNESS C2 HEAD 1
42 KEY BOARD MEMBRANE 1 89 HARNESS C3 SENSOR 1
43 SHEET KEY BOARD-SETTING 1 90 MAGENT 1
44 COVER KEY BOARD 1 91 STICKER LABEL SETTING 1
45 BRACKET CONNECTOR ASSY 1 92 STICKER IMPORTANT 1
46 PWB PK-265A 1 93 BRACKET LABEL PEEL 1
47 HARNESS C4 SWITCH ASSY 1 94 PLATE A COVER 1
48 COVER SWITCH 1 95 FRONT LCD ASSY 1
To Next Page
