ISHIDA Uni-5 Service Manual

Chapter 2 ASSEMBLY DRAWINGS
2-6 UNI-5 Service Manual
NO. PART NAME Q'TY NO. PART NAME Q'TY
21 EARTH CLAMP 2 65 HARNESS C4 SWITCH ASSY 1
22 COVER CASSETTE 1 66 ANTENNA 1
23 EARTH CLAMP 1 67 STICKER SEAL 2
24 FRAME PRINTER UPPER 1 68 PWB PK-265A 1
25 FRAME PRINTER 1 69 BRACKET CONNECTOR ASSY 1
26 HOLDER COVER 1 70 BRACKET LEVEL 1
27 BRACKET COVER 1 71 LEVEL UNIT 1
28 PANEL COVER 2 72 FRAME LEVEL 1
29 CASE CONTROL REAR 1 73 ACCESSORY PWB GUIDE SPACER 4
30 PANEL BUTTON 1 74 PWB P-999B 1
31 BUSH TORQUE 2 75 CASE A/D BOARD 1
32 BRACKET CONTROL 1 76 SCREW SEAL HEXA 1
33 POLE STAND 1 77 SCREW SEAL HEXA 1
34 BRACKET POLE STAND 1 78 HARNESS S2 24V DC POWER 1
35 PLATE B BRACKET POLE 1 79 COVER SIDE 1
36 FOOT ADJUST 5 80 BLOCK B HINGE SIDE COVER 1
37 PLATTER ASSY 1 81 HARNESS S2 FRONTLCD
(
EV
)
1
38 GUIDE PLATTER 1 82 HARNESS S2 REAR LCD 1
39 STICKER VOID 2 83 HARNESS C2 A/D 1
41 LEVEL LENS 1 84 FERRITE CORE 2
42 CAP 4 85 SHEET INSULATION POWER 1
43 CASE MAIN UPPER 1 86 GASKET 20mm 1
44 COVER PRINTER UPPER 1 87 STICKER LOCATION OUTPUT 1
45 BLOCK B HINGE PLATTER 2 88 FERRITE CORE 2
46 RUBBER PLATTER SUPPORT 5 89 FERRITE CORE 1
47 PLATTER SUPPORT 1 90 HARNESS S2 LAN 1
51 COVER HARNESS 1 91 HARNESS S2 5V POWER 1
52 PWB PK-270C 1 92 FERRITE CORE 2
53 SHEET INSULATION 1 93 POWER CORD 1
54 BASE 1 94 STICKER 'M' 1
56 HARNESS C2 POWER ASSY 1 95 LOADCELL ASSEMBLY 1
57 PLATE B RS232C 1 96 NAME PLATE SPEC 2
58 BRACKET HINGE 1 97 NAME PLATE SERIAL 1
59 COVER FRONT ELEVATE 1 99 MAGENT 1
60 POWER SUPPLY 1 100 STICKER LABEL SETTING 1
61 BRACKET POWER 1 101 STICKER IMPORTANT 1
62 CASE REAR POLE DISPLAY 1 102 BRACKET LEVEL 1
63 COVER BRACKET CONNECTOR 1 103 PLATE A COVER 1
64 COVER SWITCH 1 104 FRONT LCD ASSY 1
