Chapter 2 ASSEMBLY DRAWINGS

2-8 UNI-5 Service Manual

Parts List (Printer for each Type)

NO. PART NAME

'TY NO. PART NAME

'TY

1 THERMAL HEAD 1 30 SPRING COIL COMPRESSION 1

2 BRACKET HEAD 1 31 BOBBIN ROLL 1

3 COVER HEAD 1 32 HOUSING TORQUE LIMITER 1

4 SPRING COIL COMPRESSION 1 33 TORQUE LIMITER 1

5 PLATE A SPRING SUPPORT 1 34 BUSH 2

6 C-RING 3 36 COVER TIMING BELT 1

7 STAY HEAD 1 37 ROLLER SUPPORT CASSETTE 1

8 GUIDE LABEL 1 38 PIN SUPPORT BELT 1

9 BRACKET PRINTER 1 39 BRACKET LIMIT 1

10 SHAFT HEAD 1 40 HARNESS C3 SENSOR 1

11 SPRING COIL COMPRESSION 2 41 GEAR ROLLER 1

12 SPRING HEAD 1 42 HOLDER LABEL 1

13 PLATE AS PEEL SHAFT 1 43 LEVER GUIDE LABEL 1

14 ROLLER PRINTER 1 44 HOLDER GUIDE LABEL 1

15 TABLE LABEL 1 45 TIMING BELT 1

16 BUSH 2 46 BRACKET MOTOR 1

18 COLLAR 1 47 GEAR MOTOR 1

19 L PLATE B GUIDE LABEL 1 48 STEPPING MOTOR 1

20 GUIDE LABEL 1 50 PHOTO REFLECTOR 1

21 LEVER HANDLE 1 51 BRACKET SENSOR 1

22 PLATE B LEVER 1 52 BLOCK B LOCK 1

23 BUSH LEVER 2 53 COLLAR 1

25 BLOCK B LEVER 1 54 BRACKET MAGNET 1

26 SHAFT LEVER 1 55 COVER PRINTER FRAME 1

27 COVER ROLL 1 56 FRAME PRINTER 1

28 STOPPER HOLDER LABEL 1 57 CABLE CLAMPS 1

29 SHAFT STEP BOBBIN 1 58 HARNESS C2 HEAD 1
