6A1 – 98 4JB1/4JB1T/4JB1TC/4JG2 - ENGINE
%
Clutch Slave Cylinder
• Remove the clutch pipe fixing clips and the clip
bracket (Right hand drive models only).
• Remove the slave cylinder assembly with the flexible
hose attached, and then tie it to the frame so that it
does not interface with servicing work.
&
Exhaust Brake Assembly
'
Front Exhaust Pipe
(
Transmission Assembly
NOTE:
The exhaust pipe bracket, the gear control bracket
and the clips are sometimes installed in the wrong
position or direction confusedly. To prevent incorrect
installation of these parts, put a correct installation
mark on them.
• Support the transmission with mission jack.
CAUTION:
To prevent the falling of the transmission, tie it firmly
to the jack with a chain or belt.
Do not allow transmission to hang unsupported from
clutch. Damage to the clutch assembly will result.
6A1-98-1.tif
6A1-98-2.tif
6A1-98-3.tif
6A1-98-4.tif
