Isuzu NPR 4J Series - Fuel Tank Installation

6C - 56 ENGINE FUEL
6. Fuel Tank
• Pull out the fuel tank to the outside.
Note:
When it is not possible to pull out the fuel tank,
remove the bracket and then draw out the fuel tank
downward.
INSTALLATION
6. Fuel Tank
Note:
When the bracket was removed to take off the fuel
tank, install the bracket to the frame and tighten it to
the specified torque.
N∙m (Kg∙m/lb∙ft)
55 (5.6/41)
When mounting the fuel tank on the bracket, be sure
to place the packing section pasted on the fuel tank
securely on the bracket.
5. Band
• Tighten the band to the specified torque
N∙m (Kg∙m/lb∙ft)
12 (1.2/104)
4. Fuel Gauge Unit Connector
• Connect the fuel gauge unit connector.
3. Fuel Return Hose
2. Fuel Feed Hose
• Set the hose to the pipe more than 25 mm (0.98 in)
deep.
1. Evapo Fuel Hose
• Fill the fuel to the fuel tank.
• Connect battery ground cable.
