SERVICE INFORMATION 00 – 33

Charging System

Manufacturer HITACHI LR150-449B DENSO

Rated voltage V 12 12

Rated output A 50 40

Rotating direction

(As viewed from pulley)

Clockwise Clockwise

Pulley effective diameter mm (in) 80 (3.15) 82 (3.23)

Weight (with pump) kg (lb) 6.0 (13.27)

4JB1TC for G.E

4JB1TC for EC

6.7 (14.77)

4JB1TC for Thailand
