6B - 16 ENGINE COOLING
TENSION ADJUSTMENT
1. Cooling Fan Pulley Belt
• With AC Generator mounting and lock bolts loose,
adjust belt tension with adjuster's adjust bolt.
Tighten bolt to the specified torque
Generator Fixing Bolt Torque N∙m (Kg∙m/lb∙ft)
40 (4.1/30)
Adjust Plate Fixing Bolt Torque N∙m (Kg∙m/lb∙ft)
19 (1.9/14)
2. P/S Oil Pump and A/C Compressor Pulley Belt
• With P/S pump lock bolt loose, adjust belt tension with
adjust belt.
Tighten lock nut to the specified torque.
Lock Nut Torque N∙m (Kg∙m/lb∙ft)
27 (2.8/20)
