Isuzu NPR 4J Series - Page 340

STARTING SYSTEM 6D2 – 7
8. Overrunning Clutch
Remove the overrunning clutch from the housing.
9. Return Spring
Remove the return spring from magnetic switch.
10. Steel Ball
Remove the steel ball from the overrunning clutch.
11. Idle Pinion
Remove the idle pinion from housing.
12. Retainer
Remove the retainer from housing.
13. Roller
14. Magnetic Switch
6D2-7-1.tif
6D2-7-2.tif
6D2-7-3.tif
6D2-7-4.tif
6D2-7-5.tif
