ITC VA-6000RM User Manual

Digital Network Public Address & Voice Alarm System
- 23 -
11. Rack earth point (Note: please make sure the reliable grounding).
12. Power supply switch.
5.3.4.Technical Specifications
Electric specifications
AC power
Voltage
~220-240V/50-60Hz
Max electricity
0.3 A(Not include the 4 wired trigger output)
Fuse specification
250V/1A, the slow type
DC power
Voltage
24V DC, ±20%
Maximum current
2A(Not include the 4 wired trigger output)
Consumption
48W
Performance index
Balanced signal input/output
THD
<1% (rated power output),1KHz
Frequency response
80Hz~20KHz
Sensitivity
385mV
Impedance
10KΩ
SNR
>70dB
Contact output
8 programmable reply output
Short circuit, no voltage
8 programmable trigger input
Electrical level mode
3.3V the highest
Short circuit mode
Short circuit, no voltage
Cooling mode
Air-cooled
Protection
Delay/over temperature/short circuit/overload
Mechanical specifications
Dimension: (L*W*D)
484* 88*446 mm (19inch, 2U)
Net weight
About 7.8Kg
Installation
desktop or in 19inch rack
Color
Black
Environmental requirement
Operating Temperature
+5℃~ +40℃
Storage Temperature
-20℃~ +70℃
Relative Temperature
<95% (No condensation)
