Digital Network Public Address & Voice Alarm System
- 44 -
Position System Charger (VA-6000BC) connected decide its status attached to the corresponding
device, such as a host VA-6000MA, backup power have configured, want to know the current
configuration of the charger working status, we need to enter the corresponding DC power menu to view;
System MIC (VA-6000FM / RM) working status is determined by the host, the host can be determined
by the current host ID or host name, that means users can name the different hosts in one system
different name to differentiate them by software VA-6000ST, so that is easy to manage, of course, can
also be in the main interface, click " " to enter the "zone control" submenu View " " (behind the
numbers is the current host number), or click " " to enter submenu check " " where "EVAC
host 01" in the "01" that is the first host system, the name is the default, you can modify its own host name,
such as "total control Center" (the other system-related user-defined name (such as: host name, partition
name, group name) named character not more than six characters, 12 ASICC yards, also recommended
not to use punctuation characters mixed with ASICC definitions to not display properly, you can not use
the keyboard "| , ^ "symbol, the system for other purposes).
6.1.EVAC system controller status inquiries and operations
Click on any region Logo screen to enter the "Main Menu", click "EVAC Host" enter as shown below
"EVAC host Main Menu" (all menu items are represented as well as the underlying sub-menu with three
decimal points):
Logo Interface Main menu
Explanation:
In the "main menu", the first three menu items displayed for the system equipment status, namely EVAC
host, amplifier guide and zones amplifier, click to view real-time status of the corresponding device. The
other six menu items are: "Date & Time" is used to calibrate the system calendar; "regular program" is
used to view system timing program and weekday settings; "System Settings" is used to view and
configure system parameters; "zoning control "working for the system partition and the partition status to
view the output speech control; the" background music "for background music player control; system
self-test six menu items, a total of nine main menu items, the interface for the functional operation of the
rightmost keys, function interface associated with the current, such as the top " " means to return to
