ITC VA-6000RM User Manual

Digital Network Public Address & Voice Alarm System
- 24 -
5.4.Terminal Detector -VA-6000T
Terminal detector is to work with VA-6000MS/VA-8500S to detect the speaker loop working status, not to
be influenced by the BGM signal, no need outer power supply, easy installation.
5.4.1.Features
1. Integrated Aluminum body, elegant appearance.
2. No need outer power supply, easy installation and wiring.
5.4.2.Front Panel
1&3. Mounting hole.
2. Speaker loop bus interface.
5.4.3.Technical specifications
Electric index
AC power
Voltage
12 DC, ±3%
Maximum current
Less than0.01A
Power consumption
Less than 1W
Mechanical specifications
Dimension (L*W*D)
156*32*48mm
Net weight
About 200g
Installation
Desktop or wall mount
Color
Black
Environmental requirement
Operating Temperature
+5℃~ +40℃
Storage Temperature
-20℃~ +70℃
Relative Temperature
<95% (No condensation)
