Digital Network Public Address & Voice Alarm System
- 39 -
Frequency response
80Hz~16KHz
Sensitivity
500mV
Impedance
10KΩ
SNR
>70dB
Line Input
Distortion
<1% (rated output power), 1KHz
Frequency response
80Hz~16KHz
Sensitivity
350mV
Impedance
10KΩ
SNR
>70dB
Microphone
Sensitivity
5mV
Impedance
600Ω
Mechanical index
Dimensions(L x W x D)
256* 52*149mm
Net Weight
About 1Kg
Installation
Desktop or 19-inch rack
Color
Black
Environmental requirements
Operating temperature
+5~+40
storage temperature
-20~+70
Relative humidity
<95% (Non-condensing)
5.9.MIC extension unit --VA-6000EM
VA-6000 EM for the VA-6000 FM/RM keyboard extension, to provide more display
and control of district / group, an MIC can be extended up to seven MIC extension
units VA-6000EM, a keyboard will increases 8 partitions and corresponding
partition status indicator.
5.9.1.Features
1. 1-click partition / group selection, simple, intuitive, and clear.
2. Showy partition working status indication.
