ITC VA-6000RM User Manual

Digital Network Public Address & Voice Alarm System
- 40 -
5.9.2.Front Panel
1. Partition Operation indicator.
 Off - Indicates that the current zoning status in the absence of broadcast or is not configured properly.
 Green - Indicates the current partition is broadcasting, the audio output is ordinary.
 Red - Indicates the current partition being broadcast, the output EVAC voice or remote paging.
broadcast as RM / FM / PSTN and so on.
 Yellow - Indicates the current partition failure.
2. Zone / Group select button.
5.9.3.Technical Specifications
Electric index
DC power supply
Voltage
5V DC, ±3%
Maximum current
0.1 A
Power
0.5W
Mechanical specifications
Dimensions (L x W x D)
66*52*149 mm
Net weight
About 0.5Kg
Installation
Desktop
Color
Black
Environmental requirements
Operating temperature
+5℃ ~ +40℃
Storage temperature
-20℃ ~ +70℃
Relative temperature
<95%(Non-condensing)
5.10.Power Amplifier
VA-P series power amplifiers are mainly used for audio power amplifier system partition, it converts the
standard audio signal into a 100V constant voltage signal to drive the speakers, simultaneously detects
each channel and each line output amplifier operating status and then send to the host.
