ITech IT-M3300 Series - 10 Technical Specification; M3312

Technical Specification
10 Technical Specification
This chapter will introduce the main technical parameters of this instrument,
such as rated voltage/current/power and so on. Besides, we will introduce the
working environment and storage temperature.
♦ IT-M3312
♦ IT-M3322
♦ IT-M3332
♦ IT-M3313
♦ IT-M3323
♦ IT-M3333
♦ IT-M3314
♦ IT-M3324
♦ IT-M3334
♦ IT-M3315
♦ IT-M3325
♦ IT-M3335
10.1 IT-M3312
Parameter IT-M3312 V1.2
Load Parameter
Rated value
( 0 ℃-40
℃)
Input Voltage
0-60V
Input Current
0-30A
Input Power
0-200W
Min. operating voltage
1V at 30A
CC
Range
0-30A
Setup Resolution
10mA
Accuracy
≤0.1%+0.1%FS
CV
Range
0-60V
Setup Resolution
1mV
Accuracy
<0.1% Umax
CR
Range
0.04-600Ω
Resolution Min.0.001Ω
Accuracy
(1/Rmin)*2%: (0.04~60Ω), (1/Rmin)*5%: (60~600Ω)
CP
Range
0-200W
Setup Resolution
0.1W
