System-Related Functions

Name Description

InvDspVer The DSP version

FpgaVer The Fpga version

CommVer The communication board version

SN The serial number

Mac The firmware address

Last Cal Last calibration date

Start Time Instrument running time

4. Press [Esc] to exit.

7.5 Measuring the DUT Temperature

This series instrument features temperature measuring terminals (Temp, GND),

is used to measure the DUT temperature. The operation procedures as

following:

1. Connecting the test line

a. Loosen the screws of the measuring temperature terminals, and insert

the thermocouple. Re-tighten the screws.

b. Connecting the other end of thermocouple to DUT.

2. Observe the information

a. Press the composite keys [Shift]+[P-set](System) to enter the system

menu.

b. Rotate the knob to select the External Meter and press [Enter] to

confirm.

c. The DUT temperature and total historical regenerative power are

displayed on screen.

1：UUT Temp

2：Re-Energy

3：AHour

4：WHour

5：Reset Meas

6：Reset ReE

• UUT Temp: temperature measurement value.

• Re-Energy: the regenerative power information.

• AHour: the capacity information of the present discharge or charge

test, which is also cleared when the battery test mode or battery

simulation mode is turned on.
