Technical Specification
Voltage monitoring
External 0V~10V is 0~600V
AC parameters
Voltage range
100VAC -240VAC
OVP 264VAC
UVP 90VAC
Frequency
47Hz~63Hz
Max. current (rms） 1Aac (AC220V)
DC Offset
-0.1A~+0.1A
Environment
Working temperature
0- 40 °C
Storage temperature
-20- 70℃
Noise 60dB
External temperature measurement
Measurement range
-20℃——120℃
Measurement accuracy
±1℃
Measurement resolution 0.1℃
Efficiency
Max. efficiency (Full-load）
88%
Communication（Optional）
Communication interfaces
RS232/USB/RS485/CAN/LAN/GPIB/Analog
Mechanical parameters
Size and weight
450mm*214mm*43.5mm
Net weight 5kg
Calculation method of resistance precision range in load mode: lower limit: 1/(1/
R+(1/R)*0.05+0.004) ; Upper limit: 1/(1/R-(1/R)*0.05-0.004)
10.11 IT-M3325
Parameter IT-M3325 V1.2
Load Parameter
Rated value
( 0 ℃-40
℃)
Input Voltage
0-600V
Input Current
0-3A
Input Power
0-400W
Min. operating voltage
10V at 3A
Copyright © Itech Electronic Co., Ltd.
115
