Basic Operation
• Pin 8 controls the actual output voltage of the instrument from 0V to
500V.
• Pin 9 monitors the actual output current of the instrument: When the out-
put current is higher than the upper limit Ilim set by pin 9, the instrument
outputs the current at the value of Ilim.
5.13 View the System Information (System Info)
This menu item is used to view the system information of the instrument.
The procedures to view the system information are as follows.
1. Press the composite keys [Shift]+[P-set] (System) on the front panel to en-
ter the system menu.
2. Turn the knob to select the System Info and press [Enter].
You can use knob to view the following system information.
Parameter Description
Model Display the instrument model.
SN Display the serial number.
Main Ver Display the system version information.
Ctrl1 Ver Display the version information of the control
panel 1.
Ctrl2 Ver Display the version information of the control
panel 2.
Date Display the system time.
Voltage Max Display the maximum voltage value.
Voltage Min Display the minimum voltage value.
Current Max Display the maximum current value.
Current Min Display the minimum current value.
Power Max Display the maximum power value.
Power Min Display the minimum power value.
Resistance Max Display the maximum resistance value.
Resistance Min Display the minimum resistance value.
Copyright © Itech Electronic Co., Ltd.
102
