ITech IT-M3900D Series User Manual

Technical Specification
Storage
Temperature
-10℃～70℃
IP IP20
Isolation DC to
GND
1000Vdc
Isolation AC to
GND
3500Vdc
Cooling
Air
Dimension ( mm)
744.22mm*459mm*56.81mm
Weight( net) 12.5kg
*1: The ripple is got under three-phase AC input.
*2: At low voltage input, the set power will decrease. For more information,
please contact ITECH.
6.1.23 IT-M3906D-800-24
Parameter IT-M3906D-800-24
Rated value
Voltage
0～800V
Current 0A～24A
Power 0W～6000W
Resistance in ser-
ies （CV priority）
0～1Ω
Setup Resolution
Voltage
0.01V
Current 0.001A
Power 1W
Resistance in ser-
ies （CV priority）
0.01Ω
Read Back
Resolution
Voltage
0.01V
Current 0.001A
Power 1W
Setup Accuracy
Voltage
≤0.03% + 0.03%FS
Current ≤0.1% + 0.1%FS
Power ≤0.5% + 0.5%FS
Resistance in ser-
ies （CV priority）
≤1%FS
Copyright © Itech Electronic Co., Ltd.
165
