ITech IT-M3900D Series - Front-Panel Overview

Quick Reference
Voltage
Level
Model
Current
Power Height
IT-M3904D-300-40 40A 4kW 1U
IT-M3906D-300-60 60A 6kW 1U
IT-M3912D-300-120 120A 12kW 2U
500V
IT-M3902D-500-12 12A 2kW 1U
IT-M3904D-500-24 24A 4kW 1U
IT-M3906D-500-36 36A 6kW 1U
IT-M3912D-500-72 72A 12kW 2U
800V
IT-M3902D-800-8 8A 2kW 1U
IT-M3904D-800-16 16A 4kW 1U
IT-M3906D-800-24 24A 6kW 1U
IT-M3912D-800-48 48A 12kW 2U
1500V
IT-M3906D-1500-12 12A 6kW 1U
IT-M3912D-1500-24 24A 12kW 2U
• Naming rules for each series of model are as follows: IT-M39XXD-YYY-ZZZ,
wherein, XX means rated power; YYY means rated voltage; and ZZZ means
rated current.
• The above model is permanently connected, Equipment Class I, Pollution De-
gree 2, Installation Category II.
• Mode of operation: Continuous.
1.2 Front-Panel Overview
The front panel of this series of instruments is shown in the figure below.
