Technical Specification
Other parameters:
AC Input
*1
Grid voltage range 3phase 200V～480V
Frequency
50/60Hz
Max. apparent
power
11.0kVA
Max. input current
25Aac
Max. efficiency
92%
Power Factor 0.99
DC component
≤0.2A
Current harmonics ≤3%
Standard Interface
Standard: USB/LAN/CAN/IO
Optional: GPIB/Analog&RS232
Command Re-
sponse Time
0.1ms
Parallel Number ≤8
Working
Temperature
0～40℃
Storage
Temperature
-10℃～70℃
IP IP20
Isolation DC to GND 300Vdc
Isolation AC to GND 3500Vdc
Cooling
Air
Dimension
（D*W*H）
767.62mm*483mm*106.9mm
Weight( net) 30kg
*1: At low voltage input, the set power will decrease. For more information,
please contact ITECH.
6.1.5 IT-M3902D-32-80
Parameter IT-M3902D-32-80
Rated value
Voltage
0～32V
Copyright © Itech Electronic Co., Ltd.
119
