Technical Specification
Max. apparent
power
6.5kVA
Max. input current
12.5Aac
Max. efficiency
94.5%
Power Factor 0.99
DC component
≤0.2A
Current harmonics ≤3%
Standard Interface
Standard: USB/LAN/CAN/IO
Optional: GPIB/Analog&RS232
Command Re-
sponse Time
0.1ms
Parallel Number ≤16
Working
Temperature
0～40℃
Storage
Temperature
-10℃～70℃
IP IP20
Isolation DC to GND 600Vdc
Isolation AC to GND 3500Vdc
Cooling
Air
Dimension
（D*W*H）
744.22mm*459mm*56.81mm
Weight( net) 15kg
*1: The ripple is got under three-phase AC input.
*2: At low voltage input, the set power will decrease. For more information,
please contact ITECH.
6.1.16 IT-M3912D-300-120
Parameter IT-M3912D-300-120
Rated value
Voltage
0～300V
Current 0A～120A
Power 0W～12000W
Resistance in ser-
ies （CV priority）
0～1Ω
