ITech IT-M3900D Series - M3904 D-500-24

Technical Specification
Frequency
50/60Hz
Max. apparent power
2.25kVA
Max. input current
12.5Aac
Max. efficiency
94.5%
Power Factor 0.99
DC component
≤0.2A
Current harmonics ≤3%
Standard Interface
Standard: USB/LAN/CAN/IO
Optional: GPIB/Analog&RS232
Command Response
Time
0.1ms
Parallel Number ≤16
Working
Temperature
0～40℃
Storage
Temperature
-10℃～70℃
IP IP20
Isolation DC to GND 800Vdc
Isolation AC to GND 3500Vdc
Cooling
Air
Dimension
（D*W*H）
744.22mm*459mm*56.81mm
Weight( net) 10kg
*1: The ripple is got under three-phase AC input.
*2: At low voltage input, the set power will decrease. For more information,
please contact ITECH.
6.1.18 IT-M3904D-500-24
Parameter IT-M3904D-500-24
Rated value
Voltage
0～500V
Current 0A～24A
Power 0W～4000W
Resistance in ser-
ies （CV priority）
0～1Ω
