ITech IT-M3900D Series User Manual

Technical Specification
Dimension
（D*W*H）
767.62mm*483mm*106.9mm
Weight( net) 30kg
*1: At low voltage input, the set power will decrease. For more information,
please contact ITECH.
6.1.13 IT-M3902D-300-20
Parameter IT-M3902D-300-20
Rated value
Voltage
0～300V
Current 0A～20A
Power 0W～2000W
Resistance in ser-
ies （CV priority）
0～1Ω
Setup Resolution
Voltage
0.01V
Current 0.001A
Power 1W
Resistance in ser-
ies （CV priority）
0.001Ω
Read Back
Resolution
Voltage
0.01V
Current 0.001A
Power 1W
Setup Accuracy
Voltage
≤0.03% + 0.03%FS
Current ≤0.1% + 0.1%FS
Power ≤0.5% + 0.5%FS
Resistance in ser-
ies （CV priority）
≤1%FS
Read Back Accuracy
Voltage
≤0.03% + 0.03%FS
Current ≤0.1% + 0.1%FS
Power ≤0.5% + 0.5%FS
Voltage ripple
*1
Vp-p ≤900mVpp
Vrms ≤120mV
Setup Temperature
Coefficient
Voltage ≤30ppm/℃
Current
≤50ppm/℃
Copyright © Itech Electronic Co., Ltd.
140
