ITech IT-M3900D Series User Manual

Technical Specification
IP IP20
Isolation DC to GND 800Vdc
Isolation AC to GND 3500Vdc
Cooling
Air
Dimension
（D*W*H）
767.62mm*483mm*106.9mm
Weight( net) 30kg
*1: At low voltage input, the set power will decrease. For more information,
please contact ITECH.
6.1.21 IT-M3902D-800-8
Parameter IT-M3902D-800-8
Rated value
Voltage
0～800V
Current 0～8A
Power 0～2000W
Resistance in ser-
ies （CV priority）
0～1Ω
Setup Resolution
Voltage
0.01V
Current 0.001A
Power 1W
Resistance in ser-
ies （CV priority）
0.01Ω
Read Back
Resolution
Voltage
0.01V
Current 0.001A
Power 1W
Setup Accuracy
Voltage
≤0.03% + 0.03%FS
Current ≤0.1% + 0.1%FS
Power ≤0.5% + 0.5%FS
Resistance in ser-
ies （CV priority）
≤1%FS
Read Back
Accuracy
Voltage
≤0.03% + 0.03%FS
Current ≤0.1% + 0.1%FS
Power ≤0.5% + 0.5%FS
Copyright © Itech Electronic Co., Ltd.
160

ITech IT-M3900D Series Specifications

General

Brand	ITech
Model	IT-M3900D Series
Category	Power Supply
Language	English
