Technical Specification
Other parameters:
AC Input
*2
Grid voltage range
3phase 200V～480V
Single phase 100V～240V
Frequency
50/60Hz
Max. apparent
power
3.7kVA
Max. input current
12.5A
Max. efficiency
92%
Power Factor 0.99
DC component
≤0.2A
Current harmonics ≤3%
Standard Interface
Standard: USB/LAN/CAN/IO
Optional: GPIB/Analog&RS232
Command Re-
sponse Time
0.1ms
Parallel Number ≤16
Working
Temperature
0～40℃
Storage
Temperature
-10℃～70℃
IP IP20
Isolation DC to GND 300Vdc
Isolation AC to GND 3500Vdc
Cooling
Air
Dimension
（D*W*H）
744.22mm*459mm*56.81mm
Weight( net) 12.5kg
*1: The ripple is got under three-phase AC input.
*2: At low voltage input, the set power will decrease. For more information,
please contact ITECH.
Copyright © Itech Electronic Co., Ltd.
114
