Appendix
A Appendix
♦ Specifications of Red and Black Test Lines
♦ Fuse Replacement
A.1 Specifications of Red and Black Test Lines
ITECH provides you with optional red and black test lines, which are sold indi-
vidually and you can select for test. For specifications of ITECH test lines and
maximum current values, refer to the table below.
Model
Specification Cross Section
Length
IT-E301/10A 10A - 1m
IT-E301/30A 30A 6mm
2
1.2m
IT-E301/30A 30A 6mm
2
2m
IT-E301/60A 60A 20mm
2
1.5m
IT-E301/120A 120A 50mm
2
2m
IT-E301/240A 240A 70mm
2
1m
IT-E301/240A 240A 70mm
2
2m
IT-E301/360A 360A 95mm
2
2m
For maximum current of AWG copper wire, refer to table blow.
AWG 10 12 14 16 18 20 22 24 26 28
The Maxi-
mum Current
Value( A)
40 25 20 13 10 7 5 3.5 2.5 1.7
AWG ( American Wire Gage), it means X wire ( marked on the wire). The table
above lists current capacity of single wire at working temperature of 30°C. For refer-
ence only.
Copyright © Itech Electronic Co., Ltd.
146
