Power Supply Function
2. Use knob or Up/Down key to select 2.BATTERY: Off and press [Enter].
The interface is displayed as follows:
FUNCTION BATTERY
Run Edit
3. Press the Left/Right key to select Edit and press [Enter].
4. Press the Left/Right key to select Charge or Discharge and press [Enter].
5. Set the charging voltage (Charge V) or discharging voltage (Discharge V),
charging current (Charge I) or discharging current (Discharge I) and the
other parameters, and then press [Enter] to confirm.
After the parameter setting is completed, the interface returns to the Battery
function main interface and displays as follows:
FUNCTION BATTERY
Run Edit
6. Press the Left/Right key to select Run and press [Enter].
The instrument will enter the battery test mode and wait for the battery test
to be triggered.
7. Turn on the [On/Off].
8. Based on the selected trigger method, perform the trigger operation.
The trigger method of the battery test is consistent with the trigger method
of the List function, that is, the List trigger source is also effective for the
Battery function.
If you want to stop running during the battery test, you can do the following:
Press the composite keys [Shift]+[I-set] (Function) on the front panel to enter
the function menu.
At this point, the interface will prompt whether to stop the running of the Func-
tion (FUNCTION STOP?), you can press the Left/Right key to select Yes, then
the current running will be stopped, and the Function menu item will be dis-
played, you can re-enter the Function menu for editing; if No is selected, it
means that the current running will not be stopped, and the main interface of the
system is displayed.
4.6.3 Built-in Waveform Function
The IT6000C series power supply supports built-in waveforms for user to exe-
cute the test directly. The protocols/standards involved in the built-in waveforms
include the following:
Copyright © Itech Electronic Co., Ltd.
86
