Quick Start
3U Model
1 Power On/Off switch
2 Vacuum fluorescent display
(VFD)
3 Function and composite keys
4 Numeric and composite keys
5 Up, down, left, and right cursor navigation
keys and Enter key
6 Push-on knob
7 Vent hole
8 USB storage device connection port
2.2.1 Keyboard Introduction
The keyboard introduction of IT6000C series Bi-directional Programmable DC
Power Supply is shown as follows.
Table 2–1 Keys Description
Keys Description
[Esc] Press this key to exit the current operation interface.
[V-set] / Config Set the output voltage value / Enter the Config menu of
the power supply
Copyright © Itech Electronic Co., Ltd.
12
