Quick Start
Keys Description
In CV priority (default) mode, press [V-set], the inter-
face displays “Vs=0.00V” (Setting value of voltage).
In CC priority mode, press [V-set], the interface dis-
plays “Vh=0.00V” (Upper limit of voltage), and press
[V-set] again, the interface displays “Vl=0.00V”
(Lower limit of voltage).
[I-set] / Function Set the output current value / Enter the Function menu
of the power supply
In CV priority (default) mode, press [I-set], the inter-
face displays “I+=0.00A” (Upper limit of current) ,
and press [I-set] again, the interface displays “I-= –
0.00 A” (Lower limit of current). In CC priority mode,
press [I-set], the interface displays “Is=0.00A” (Set-
ting value of current).
[P-set] / System Set the output power value / Enter the System menu
Press [P-set], the interface displays “P+=0.00W”
(Upper limit of power) , and press [P-set] again, the
interface displays “P- = – 0.00W” (Lower limit of
power) .
[Recall] / Protect Returns the instrument to the specified setup. / Enter the
Protect menu of the power supply
[Shift] Composite key, combined with other keys to realize func-
tions marked above keys.
[On/Off] / Trigger
• Turn the power supply output on or off. When lit, indi-
cates that the output is enabled or on.
• Generate a local trigger signal.
[0]-[9] Numeric keys
[Shift]+[1] (Log) Enter the data logging function menu.
[Shift]+[2] (Lock) Turn the keyboard lock on or off.
[Shift]+[3] (Local) Switch remote control mode to local control mode.
