ITech IT6090C-500-450

Quick Start
The models included in the IT6000C series are as follows:
500V 1,500V Height (with
bare machines
overlapped)
Height (consti-
tuting cabinet)
IT6006C-500-30 –
3U
–
IT6012C-500-60 –
IT6018C-500-90 IT6018C-1500-30
IT6036C-500-
180
IT6036C-1500-60 6U
IT6054C-500-
270
IT6054C-1500-90 9U 15U
IT6072C-500-
360
IT6072C-1500-
120
12U
IT6090C-500-
450
IT6090C-1500-
150
15U 27U
IT6108C-500-
540
IT6108C-1500-
180
18U
IT6126C-500-
630
IT6126C-1500-
210
21U
IT6144C-500-
720
IT6144C-1500-
240
24U
Naming rules for each series of model are as follows: IT 6XXXC-YYY-ZZZ,
wherein, XXX means rated power; YYY means rated voltage; and ZZZ
means rated current.
As a bipolar power supply, this series can output and absorb electric energy.
The current and power input capacity is same as the output capacity. For ex-
ample, the maximum rated value of the output power of the IT6018C-500-90
model is 18,000W, and the maximum rated value of input power is also
18,000W.
2.2 Front-Panel Overview
For the IT6000C series Bi-directional Programmable DC Power Supply, all front
panels of the 3U model are the same, and the operation panels of other models
are the same as those of the 3U model. The following is the front panel sche-
matic of the 3U model.
