Power Supply Function
For the bi-directional power supply, you can set the direction of the current
(output / input), that is, control the positive or negative current value by press-
ing the [+/-] key.
4.3 Set the Output Power
Press [P-set], the interface displays “P+=0.00W” (Upper limit of power) , and
press [P-set] again, the interface displays “P- = – 0.00W” (Lower limit of power)
.
The range of power settings is between the data ranges defined in the specifica-
tions. When [P-set] key is pressed, the key light is lit and the output power value
can be set. Press numeric keys or rotate the knob to adjust the value in the
power setting area indicated by the cursor. This value takes effect when you
press [Enter].
For the bi-directional power supply, you can set the direction of the power
(output / input), that is, control the positive or negative power value by press-
ing the [+/-] key.
4.4 Configuration Menu Function for Power
Supply
This section gives an overview of the configuration menu of the IT6000C series
power supply.
The procedures to operate the configuration menu are as follows.
1. Press the composite keys [Shift]+[V-set] (Config) on the front panel to enter
the configuration menu.
The VFD shows configuration menu items and each menu item is marked
with a number. The user can use up and down keys or knob to scroll pages
to view the other menu items.
2. Press [Enter] to select the desired menu item.
Enter the parameter setting interface of this menu item.
3. After finishing the menu setting, press [Enter] key to save the setting.
Copyright © Itech Electronic Co., Ltd.
65
