Basic Operation
The user can select the following data sources for recording:
• Voltage
Only records voltage data during the data acquisition period.
• Current
Only records current data during the data acquisition period.
• Voltage and current
Records current and voltage data during the data acquisition period.
Configure the Function Menu
1. Press the composite button [Shift]+[1] (Log) on the front panel to enter the
configuration menu of the data logging function.
The parameters are described as follows:
Menu Item Description Setting
Sample
Period
This parameter indicates the data
sampling interval (unit: s), that is, the
test data is recorded once every X
seconds.
The input range supported by the in-
strument is: 0 - 9
Set the value by in-
putting the value
through the number
key or rotating the
knob.
Duration This parameter indicates the time for
data recording (unit: s), namely, the
data recording will be completed in Y
seconds and be ready for the next
data record.
The input range supported by the in-
strument is: 0 - 3600
Source This parameter indicates the source
of recorded data, including voltage
(V), current (I), voltage and current
(V/I).
Use the Left and
Right arrow key or
the rotation knob to
select.
Copyright © Itech Electronic Co., Ltd.
23
