Basic Operation
interface and the
analog interface
share an inter-
face position.
Parity
Parity bit: N (No parity) / E (Even
parity) / O (Odd parity)
Stopbit Stop bit: 1/2
GPIB Select GPIB communication interface.
Address
Set the communication address (1
to 30).
Parallel
Set the instruments to parallel operation mode.
Single
Set the instrument to single mode, i.e., disable
the parallel operation mode.
Master Set the instrument to master mode.
Total: Number of parallel instruments.
Slave Set the instrument to slave mode.
Digital Port
Set Digital I/O
By default, the menu item displays 7 options. You can set
parameters for each option respectively. After setting, the
corresponding change to each option becomes valid imme-
diately. When re-entering DigPort, the interface can display
the changed option. For detailed introduction of menus and
functions, see 3.6.7 Digital I/O Function (Digital Port).
IO-1. Ps-Clear, Not-
Invert
Function setting of pin 1
IO-2. Ps, Not-Invert
Function setting of pin 2
IO-3. Off-Status, Not-
Invert
Function setting of pin 3
IO-4. Ext-Trig, Not-
Invert
Function setting of pin 4
IO-5. INH-Living, Not-
Invert
Function setting of pin 5
IO-6. Sync-On, Not-
Invert
Function setting of pin 6
IO-7. Sync-Off, Not-
Invert
Function setting of pin 7
Ext-Program
External Analog Function. This function is optional. The
menu can only display when corresponding board card is in-
serted. For detailed menu settings, see 3.6.8 (Optional)
Analogue Function (Ext-Program).
System Reset Select whether to restore the factory default settings or not.
System Info View the system information.
Model
Display the instrument model.
MAC Addr
Display the MAC address, that is, the physical
address.
SN
Display the serial number.
Copyright © Itech Electronic Co., Ltd.
29
