Function and Features
Step Count: total count of steps contained
in the Wave file (1-10)
Step1 Voltage: Voltage setting of step 1 (0-
Vmax)
Step1 Current: Current setting of step 1 (0-
Imax)
Step1 LoadCurr: Load current setting of
step 1 (0-Imax(load))
Step1 Width: Width setting of step 1
(0.001s-24h)
Step1 Slope: Slope setting of step 1
(0.001s-24h)
Save to Wave: save to the Wave file
Wave edit and List edit have no order of priority.
Editing Wave
List file can arrange and link several Wave files. The user can pre-edit several
Wave files and select edited wave file that meets requirements during usage. In
this series of power supply, at most 100 wave files can be edited.
Take an example for 3 steps, the steps of editing Wave file are as follows:
1. Press [Shift]+I-set(Function) to enter List operation.
2. Press the Right key to select EditWave from the menu, and press [Enter] to
confirm.
3. Press numeric key to input the number of Wave file under edit, where Recall
Wave= 01, and press [Enter] to confirm.
Recall Wave： 01
4. Press numeric key to input total count of steps for the current Wave file,
where Step Count=03, and press [Enter] to confirm.
Step Count=03
5. Press the numeric key to set the voltage, current, load current,slope and
width of the Wave step 1 in sequence.
Step1 Voltage = 1V
Step1 Current = 1A
Step1 LoadCurr=1A
Step1 Width = 1s
Copyright © Itech Electronic Co., Ltd.
44
