Function and Features
When recalling this waveform, to ensure the validity of the waveform，the
user needs to enable the internal load function at first and then set the
current of internal load to the maximum value. Please refer to 3.9.8 Load
Function for the detailed operation. And the CC/CV priority of power need to
be CV option.
E-02 Transient Overvoltage Pulse
Transient overvoltages may occur in the electric system due to the switching off
of loads and due to short accelerator tip-ins. These overvoltages are simulated
by means of this test. This test may be used for the electrical life test. The test
pulse of E-02 Transient overvoltage is shown in the next figure.
E-04 Jump Start
External starting of the vehicle is simulated. The maximum test voltage results
from commercial vehicle systems and their increased power supply voltage.
The test pulse of E-04 Jump start is shown in the next figure.
Copyright © Itech Electronic Co., Ltd.
69
