Operation and Application

Timer Set the output time.

4.8.2 List Function

IT7200 List mode supports program complex waveform editing. The users can

edite 5 list files (List1 to List5) , each file can be edited up to 50 steps. Each step

settable parameters include: basic waveform (incl. THD and user defined wave-

form), AC/DC amplitude, slew rate, frequency, dwell time, start/stop phase an-

gle, times of repetition etc. This function with complex waveforms can help

users to simulate grid disturbance, periodic power off and so on.

This power supply needs to use the IT7200 Series Software to edit the List func-

tion contents, and download the List files to local equipment. Then, the instru-

ment can locally run the List function. The user can also run all functions of the

List in the IT7200 Series Software.

Operation Steps:

1. Edit List Program.

Please refer to “Edit List File” or “Export/Import List in PC” in the IT7200 Ser-

ies Software User Manual to edit the List file.

2. Set the List mode.

a. Press the composite keys [Shift] + [I-set](Function) to enter function

menu interface.

1:List Mode = Off

2:List Trigger = On

b. Rotate the knob to select List Mode and press [Enter] key to confirm.

c. Rotate the knob to select the name of the List file to be run and press

[Enter] key to confirm.

• Off: Default value, indicating that the List Mode function is disabled.

• 1: indicate that the List Mode function is enabled, and List 1 file is

called.

• 2: indicate that the List Mode function is enabled, and List 2 file is

called.

• 3: indicate that the List Mode function is enabled, and List 3 file is

called.

• 4: indicate that the List Mode function is enabled, and List 4 file is

called.

• 5: indicate that the List Mode function is enabled, and List 5 file is

called.

3. Set the trigger mode to run the List.

a. Select List Trigger in the Function menu interface and press [Enter] key

to confirm.
