Getting Started
20.1V 0.08A
1.68W DC MODE
When the power supply is used as a DC power supply, please understand
the related ripple parameters for this instrument when served as a DC power
supply. If there are strict noise requirements, it is necessary to add additional
DC noise filter to obtain low noise and good and stable DC voltage for test.
3.3 Applying Waveform Output
IT7200 can be used as a waveform generator. In the following process, IT7200
is configured as a waveform generator and outputs 10V/50Hz Sine wave.
1. Press the[Shift]+[3] (AC) key to set the instrument to AC output mode.
50.0V 6.00A 60.0Hz
0.00W 0.00Ip 0.00PF
2. Set the AC Voltage.
a. Press [V-set] key to position the cursor to the voltage setting value.
50.0V 6.00A 60.0Hz
0.00W 0.00Ip 0.00PF
b. Rotate the knob clockwise to increase the voltage setting value and anti-
clockwise to decrease the value. Set the required value.
The knob can be used together with the left/right navigation keys. Press
the left/right navigation keys to move the cursor to a digit. Rotate the
knob to change the digit value.
c. Press [Enter] key to confirm the voltage setting value.
Press [Esc] key to exit the input mode.
3. Set the AC Frequency.
a. Press [F-set] key to position the cursor to the frequency setting value.
10.0V 6.00A 60.0Hz
0.00W 0.00Ip 0.00PF
b. Rotate the knob clockwise to increase the frequency setting value and
anticlockwise to decrease the value. Set the required value.
The knob can be used together with the left/right navigation keys. Press
the left/right navigation keys to move the cursor to a digit. Rotate the
knob to change the digit value.
c. Press [Enter] key to confirm the frequency setting value.
Press [Esc] key to exit the input mode.
4. Set the AC Phase Angle.
a. Press the composite keys [Shift]+[V-set](Config) to enter into the config-
uration menu interface.
1:I Range = High
Copyright © Itech Electronic Co., Ltd.
31
To Next Page
