ITech IT7200 Series User Manual

Technical Specification
Parameter IT7221
Other
Dimension
Without foot post,
protective cover
449.4 mm(D)x 214.5 mm(W)x 88.2 mm(H)
With foot post, pro-
tective cover
493.9 mm(D)x 255 mm(W)x 110 mm(H)
Weight 8.05kg
*1: Min voltage for THD test is 100Vac.
*2: Min voltage for frequency display accuracy is 100Vac.
*3: Tested with pure resistive load.
*4: The minimum voltage for the applicable range of the specifications is 3Vac.
*5: The applicable range of frequency resolution is 45~99.9Hz.
*6: The specification applies to an ambient temperature range of 23±2 degrees
Celsius.
6.2 IT7222
Parameter IT7222
AC Input
Voltage 220-230Vac (±10%)
Phase
Single-phase
Frequency
47-63Hz
Max.current 5.5A
AC Output
Max. output power
600VA
Max. output voltage
300V
Output phase Single-phase
Current range(rms)
6A
Current range(peak)
18A
Output frequency range
45 - 500Hz
Phase angle degree range
0 – 359.9°
THD*1*3 (Resistive Load)
≤0.3% at 50/60Hz ;
≤1% at 45-500Hz
Copyright © Itech Electronic Co., Ltd.
75
