ITech IT7200 Series User Manual

Technical Specification
6 Technical Specification
This chapter will introduce the rated voltage, current, power and many other
main parameters of IT7200 series power source.
♦ IT7221
♦ IT7222
6.1 IT7221
Parameter IT7221
AC Input
Voltage 220-230Vac(±10%)
Phase
Single-phase
Frequency
47-63Hz
Max.current 3.3A
AC Output
Max. output power
300VA
Max. output voltage
300V
Output phase Single-phase
Current range(rms)
3A
Current range(peak)
9A
Output frequency range
45 - 500Hz
Phase angle degree range
0 – 359.9°
THD*1*3 (Resistive Load)
≤0.3% at 50/60Hz ;
≤1% at 45-500Hz
Crest factor 3
Line Regulation*3 (Resistive Load)
≤0.06%
Load Regulation*3 (Resistive Load)
≤0.15%
Output voltage
(VAC) *4
Resolution 0.1V
Accuracy ±(0.2% +0.2%×F.S.)
Frequency
Resolution 0.1Hz
Accuracy
±0.1%
Copyright © Itech Electronic Co., Ltd.
73
