ITech IT8811 User Manual

Function and Features
Copyright © ITECH Electronic Co., Ltd. 22
2. Operate key and move to On. Press [Enter] key and select
Pulse. Press [Enter] key (The Trig lamp that indicates VFD screen status
is on)
TRANSITION
Continuous Pulse Toggle
3.
Operate key and select high rate and low rate. Move to the
High-Rate and press [Enter] key.
TRANSITION
High-Rate Low-Rate
4.
Set ascending slope and press [Enter] key.
TRANSITION
Rise up=30.000A/uS
5.
Set descending slope and press [Enter] key.
TRANSITION
Rise down=30.000A/uS
6.
Set A value and press [Enter] key.
TRANSITION
Level A=1A
7.
Set B value and press [Enter] key.
TRANSITION
Level B=2A
8.
Set time width and press [Enter] key.
TRANSITION
Pulse Width=5S（0.00002-3600S）
9.
Start dynamic test and operate key. Move to On and press
[Enter] key.
TRANSITION
On Off
10.
Enter the dynamic test mode.
10.0000V 0.0000A
0.00W 0 TRAN
11.
Press [On/Off] key to open input and press [Shift] + key (Triggering
key)
The load will switch after receipt of every trigger signal. The load will
continuously switch between A and B value. Time of operations is shown at
bottom right.
12.
Press [CC]/ [CV]/ [CR]/ [CW] key or any composite function key to exit
dynamic test function. Repeat Steps 1-11 to continue parameter setting
and operation of dynamic test.
3.9.3 Toggle mode
Under toggle mode, after enabling dynamic test operation, the load will be
switched continuously between A value and B value after receipt of every
trigger signal.
