PROGRAM
Complete-Stop Failure-Stop
13. Determine whether to link to next group of test file. If it is to link to second
group, press [2] key. 0 means not to link to other test files. Press [Enter]
key.
PROGRAM
Chain Program File=0 (0-10)
Correspondence Table of Auto test files and step parameter saving.
Program 1
Sequence
1
2
3
4
5
6
7
8
9
10
Save Group
1
2
3
4
5
6
7
8
9
10
Program 2
Sequence
1
2
3
4
5
6
7
8
9
10
Save Group
11
12
13
14
15
16
17
18
19
20
:
:
Program 10
Sequence
1
2
3
4
5
6
7
8
9
10
Save Group
91
92
93
94
95
96
97
98
99
100
14. Save the programmed files in EEPROM. A total of 10 groups of files can be
saved. If it is to save edited files in group 1, press [1] key. Press [Enter]
key.
PROGRAM
Save Program File=1 (1-10)
15. Press [ESC] key to exit editing menu.
The above steps only set entire framework of auto tests. Additional setting is
required for specific parameters in each step. This design will facilitate
modification of parameters in a single step.
16. Select desired working mode and set working parameters. Press [Shift] +
[CV] to enter parameter setting.
10.0000V 0.0000A
0.00W CC=1.000A
17. It is assumed that step 1 edits CC mode as follows: current: 2A, maximum
voltage value: 10V, and minimum voltage value: 2V; and step 2 edits CV
mode as follows: voltage: 3V, maximum current value: 5A, and minimum
current value: 0A. After parameter setting in each step, press [ESC] to exit
setting menu. Press [Shift] +
[4] key for saving. Settings at each step
should be independently saved. Refer to the Correspondence Table
for saving position.
18. It is necessary to recall test files for running after editing auto test files.
Recall test file for running
To recall edited test files from EEPROM quickly after re-energizing instrument,
refer to the method below.
1. Press [Shift] + [6] keys.
PROGRAM
Run Recall Edit
2. Operate
key, select Recall and press [Enter] key.
RECALL PROGRAM
